2MHPTM-BB High precision human body temperature measurement black body (DISCONTINUED)
- Real-time data transmission
- Auto focus, fast and accurate temperature measuring
- Compact size: easy to install in small spaces
- Patented intelligent compensated temperature measurement algorithm: accuracy of ±0.3°C
Product Documents
Downloads
- Frequency 50Hz, Gigabit network: support temperature data transmitting real-time
- Auto focus, fast and precise temperature measuring Spot/line/area/isotherm analysis tools, simpler and more flexible to retrieve temperature data
- Compact size: easily install in small space
- Support multi-protocols: TCP, UDP, ICMP, DHCP, RTSP
- Patented intelligent compensated temperature measurement algorithm: accuracy of ±0.3°C
Weight | 6 lbs |
---|
MAIN DATA | |
Working Voltage | AC180~240V |
Power Consumption (Highest) | 260W |
Environment Temperature | 0°C~ 40.0°C |
Working Temperature | Indoor 5°C~ 100°C |
Calibration Temperature | 35°C~ 37°C |
Emissivity | 0.97±0.02 |
Temperature Resolution | 0.1°C |
Settle Time | ≤5min |
Temperature Measurement Accuracy | ±0.2°C@36°C |
Temperature Stability | ±( 0.1~0.3 )°C/h |
Effective Emissivity Surface | 100mm x 80mm |
Size (L x W x H) | 195 x 150 x 110mm |
