2MN-8008-P 8-CH Network Video Recorder

  • Support Ultra 265/H.265/H.264 video formats
  • 8-channel input
  •  Up to 8 Megapixels resolution recording
  • 1 SATA HDDs, up to 8TB for each HDD
  • Supports cloud upgrade

Product Documents

The 2M Technology 4 Channel Network Video Recorder is a high tech device. The product offers HDMI and VGA output support. This allows the customer to incorporate a monitor for video display. In addition to the 8 megapixel resolution recording capability, the NVR is also able to support H.264 video formats. Lastly, the ANR technology allows the user to increase the storage reliability.

Key Features

  • Support Ultra 265/H.265/H.264 video formats
  • 8-channel input
  • Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile C, Profile Q, Profile A, Profile T
  • Support 1-ch HDMI, 1-ch VGA, HDMI at up to 4K(3840×2160) resolution
  • HDMI and VGA simultaneous output
  • Up to 8 Megapixels resolution recording
  • 1 SATA HDDs, up to 8TB for each HDD
  • ANR technology to enhance the storage reliability when the network is disconnected
  • Support cloud upgrade
Signal Type

Number of Channels

PoE Channels

Internal Hard Drives SATA Ports

1 SATA Hard Drives

Resolution

4 Megapixel (2592 x 1520)

Series

Professional Series

VIDEO & AUDIO
IP Video Input8-ch
Network
Incoming Bandwidth48Mbps
Outgoing Bandwidth48Mbps
Remote Users128
ProtocolsP2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output






HDMI/VGA Output

HDMI:

4K (3840×2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz,

1600×1200 /60Hz, 1280×1024 /60Hz, 1280×720 /60Hz, 1024×768

/60Hz VGA:

1920x1080p /60Hz, 1920x1080p /50Hz, 1600×1200 /60Hz,

1280×1024 /60Hz, 1280×720 /60Hz, 1024×768/60Hz

Recording Resolution8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Audio Output1-ch, RCA
Synchronous Playback8-ch
Corridor Mode Screen3/4/5/7/9
Decoding
Decoding formatUltra 265, H.265, H.264
Live view/ Playback8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Capability1 x 4K@30, 2 x 4MP@30, 4 x 1080p@30, 8 x 720p@30
Hard Disk
SATA1 SATA interfaces
Capacityup to 8TB for each disk
External Interface


Network Interface



1 RJ45 10M/100M self-adaptive Ethernet Interface

USB InterfaceFront panel: 1 x USB2.0; Rear panel: 1 x USB2.0
GENERAL


Power Supply

12V DC

Power Consumption: ≤ 5 W( without HDD )



Working Environment

-10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90%

RH(non-condensing)



Dimensions



260 x 240 x 43 (mm) (10.2″ x 9.4″ x 1.7″) (in)
