2MVIP-4MIR30UA-P 4MP WDR Vandal-Resistant Network IR Fixed Dome Camera
- WDR: 120 dB
- IP Rating: IP66
- Shutter: Auto/Manual, 1/6~1/100000 s
- Sensor: 1/3″ 4MP progressive scan CMOS
Product Documents
The 2M Technology 4MP WDR Vandal-resistant Network IR Fixed Dome Camera is an advanced optical surveillance camera. The product offers customizable OSD (On-Screen-Display) and up to 120 dB WDR (Wide Dynamic Range). In addition to these features, the camera also has the ability to capture images or footage indoors or outdoors with the Smart IR illumination. Lastly, the product is vandal resistant and has a weatherproof durability rating of IP66.
Key Features
Optics
- Day/night functionality
- Smart IR, up to 30 m (98 ft) IR distance
- Up to 120 dB WDR (Wide Dynamic Range)
- 3D DNR (Digital Noise Reduction)
Compression
- H.265, H.264, MJPEG
- Embedded smart algorithm
- ROI (Region of Interest)
- Customized OSD
Network
- ONVIF Conformance
Structure
- Wide temperature range: -35°C to 60°C (-31°F to 140°F)
- Wide input voltage range of ±25%
- IK10 vandal resistant
- IP66
| Weight | 0.99 lbs |
|---|---|
| Dimensions | 4.28 × 4.28 × 3.2 in |
| Series | Professional Series |
| Resolution | 4 Megapixel (2592 x 1520) |
| Signal Type | |
| Night Vision Distance | 30 Meters (100 feet) |
| Night Vision Type | Infra Red (IR) LED |
| Lens | Fixed 2.8mm Lens |
| Features | Ultra WDR 120DB, Audio Input |
| Camera | |||
| Sensor | 1/3″, 4 megapixel, progressive scan C MOS | ||
| Shutter | Auto/Manual, 1/6~1/8000 s | ||
|
Lens |
2.8 mm@F2.0
Angle of view(H): 93.0° |
3.6 mm@F2.0
Angle of view(H): 72.0° |
6.0 mm@F2.0
Angle of view(H): 42.0° |
| Day/Night | IR-cut filter with auto switch (ICR) | ||
|
Min. Illumination |
Colour: 0.02 Lux (F2.0, AGC ON)
0 Lux with IR |
||
| S/N | >55 dB | ||
| WDR | 120 dB | ||
| Video | |||
| Max. Resolution | 2592 × 1520 | ||
| Video Compression | H.265, H.264, MJPEG | ||
|
Frame Rate |
4MP (2592×1520): Max. 20 fps; 4MP (2560×1440): Max. 25 fps
3MP (2048×1520): Max. 30 fps; 1080P (1920×1080): Max. 30 fps |
||
| 9:16 Corridor Mode | Supported | ||
| ROI | Supported | ||
| Video Streaming | Triple | ||
| OSD | Up to 8 OSDs | ||
| Privacy Mask | Up to 4 areas | ||
| Smart | |||
| Behavior Detection | Intrusion, crossing line, motion detection | ||
| Exception Detection | Audio detection | ||
| Intelligent Identification |
Face detection |
||
| Statistical Analysis | People counting | ||
| Audio | |||
| Audio Compression | G.711 | ||
| Two-way audio | Supported | ||
| Storage | |||
| Edge Storage | Micro SD, up to 128 GB | ||
| Network | |||
|
Protocols |
L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SIP, 802.1x | ||
| Compatible Integration |
ONVIF, API |
| Interface | |
|
Audio I/O |
Input: impedance 35 kΩ; amplitude 2 V [p-p] |
| Output: impedance 600 Ω; amplitude 2 V [p-p] | |
| Alarm I/O | 1/ 1 |
|
Network |
10M/100M Base-TX Ethernet |
| General | |
|
Power |
12 V DC, or PoE (IEEE802.3 af) |
| Power consumption: Max 5.5W | |
| Dimensions (Ø x H) | Φ108.5 x 81 mm (Ø 4.28” x 3.2”) |
| Weight | 0.45 kg (0.99 lb) |
| Working Environment | -35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 95% RH(non-condensing) |
| Vandal Resistant | IK10 |
| Ingress Protection | IP66 |
