2M-POE-24+ 24-Port PoE Switch

  • 24×10/100Mbps Ethernet ports
  • 2×Gigabit combo ports (RJ45 and SFP)
  • All 100Mbps ports support PoE
  • Up to 250m transmission distance on EXTEND mode
  • Easy to use

Product Documents

2M-POE-24+ 24-Port PoE Switch

Features:

  • 24×10/100Mbps Ethernet ports
  • 2×Gigabit combo ports (RJ45 and SFP)
  • All 100Mbps ports support PoE
  • PoE complies with IEEE802.3af/at, up to 30W for single port
  • Up to 250m transmission distance on EXTEND mode
  • Easy to use, no need to configure
  • High quality with all metal housing
SKU: 2M-POE-24+ Categories: , , Tags: , , , ,
Dimensions17.3 × 11 × 1.7 in
PoE Channels



Ports

24×10/100Base-TX autosensing Ethernet ports

(all support PoE) 2×Gigabit combo ports (RJ45 and SFP)



Port Attribute

10/100/1000Mbit/s transfer rate

Half-duplex, full-duplex and auto-negotiation Auto MDI/MDIX





Standards

IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3z 1000BASE-X ANSI/IEEE 802.3 NWay

IEEE 802.3x flow control

IEEE 802.3af and IEEE 802.3at PoE

PoE

MAC4K
Packet Forwarding Rate6.55Mpps
Switching Capacity8.8Gbps




EXTEND Mode

Disabled: all ports can communicate with each other, and monitoring optimization is disabled.

Enabled: downlink ports can only communicate with uplink ports; monitoring optimization is enabled, and transmission distance can be extended to up to 250 meters.











Status LEDs

Link/Act (steady green): link is normal

Link/Act (flashing green): data is being forwarded Link/Act (off): no link

PoE (steady orange): the port is powering a powered device properly

PoE (off): the port is not connected to any powered device or is not supplying power

Power (steady green): AC input is normal Power (off): AC input is abnormal
PoE802.3at/af, Max PoE capacity: 400 W
Consumption≤ 450 W
AC Voltage100-240 V
Operating Temperature0°C-40°C (32°F-104°F)
Operating Humidity10%-85%
Storage Temperature-10°C-70°C (14°F-158°F)
Storage Humidity10%-90%
Dimensions (WxDxH)440mm×280mm×44mm (17.3″×11″×1.7″)
