2MTHFR-2M Face Recognition Access Control Terminal with Digital Temperature Measurement Module

  • Non-contact detection,
  • Detects people with abnormal body temperature
  • Verifies personnel information and detects their temperature
  • Set temperature detection settings
  • Measurement range is between 30˚C to 45˚C,
  • Accuracy can reach 0.1˚C, measurement deviation is less than or equal to 3˚C
  • Measurement distance is 1 meter
  • Learning algorithm
  • Face recognition accuracy rate > 99%, false rate <1%

Product Documents

2MTHFR-2M digital temperature measurement face recognition access control terminal is an access control device with precise recognition rate, large storage capacity and fast recognition, which integrates 2M face recognition technology and non-contact temperature detection technology. The digital temperature measurement module supports rapid body temperature detection. Thus, the product can achieve face recognition and temperature detection at the same time, and support warning people with abnormal body temperature. It can be widely applied in the crowded places, such as smart communities, schools, office buildings, hospitals and other important areas

Features:

  • Non-contact detection, support warning people with abnormal body temperature
  • Body temperature detection and personnel information binding, which can quickly confirm personnel information and do body temperature detection
  • Configure temperature detection threshold value, and personnel access authority can be configured through temperature detection threshold value
  • Non-contact temperature detection module, measurement range is between 30˚C to 45˚C, measurement accuracy can reach 0.1˚C, measurement deviation is less than or equal to 3˚C, and measurement distance is 1 meter
  • Deep learning algorithm model based on 2M independent intellectual property rights, face recognition accuracy rate > 99%, false rate <1%
  • Built-in deep learning dedicated chip, supports local offline recognition, 10,000 face capacity, face whitelist (1:N)
  • Fastest recognition time 0.2 seconds, various model merge mode are used to reduce false rate and increase pass rate
  • WDR, 2MP (1080P) low illumination wide-angle camera and F1.6 large aperture lens for capturing high quality image with various complex lighting scenes
  • Support anti-spoofing detection based on deep learning algorithm, effective against fraud such as photo and video
Operation System Linux
Face Recognition Accuracy Rate >99%
Face Recognition Time 200ms
Face Capacity 10,000
Card Capacity 100,000
Storage Capacity 4GB
Event Capacity 30,000 (with images)
Measurement Range 30°C – 45°C
Measurement Accuracy 0.1°C
Measurement Deviation ≤±0.3°C
Measurement Distance 1m


Authentication Mode

Face Whitelist: (1:N)
Card:(1:N)
Face +Body temperature
Card Type Mifare 1 Card
User Management Support user library addition, deletion, update
Record Management Support local recording and real-time upload


Interface

LAN×1, Wiegand Input×1, Wiegand Output×1, RS485×1, Alarm Input×2, Alarm Output×1, USB2.0×1, Lock×1, Door Contact ×1, Exit Button×1
Power Supply Input 12V±25% DC
Screen Touch Screen, Size:7 inch, Resolution: 600×1024
Camera Dual Lens, 2MP, 1080P
Supplement Light LED soft light and infrared light
Dimensions (L×W×H) 134.0mm×33.0mm×305.0mm
Working Environment For access control terminal: -20°C~+65°C, Relative Humidly<95% (non-condensing)
Protection Level Both terminal and module: IP 54
Application Situation Indoor, No wind
