2MTHWT-1 Human Body Temperature Measurement Security Gate (2 Sensors: Wrist and Forehead)

  • Non-contact detection to avoid cross infection
  • ADA model also available
  • Wrist and Forehead temperature sensors
  • Temperature measurement distance: 1.5″-3.1″ inches, error <0.2˚C
  • Minimizes the margin of error that comes with manual temperature measurement

Product Documents

Overview

The human body temperature measurement check gate can be used to detect abnormal human body temperature. This model includes 2 temperature sensors one for the forehead and a lower one for the wrist. It is suitable for the control of crowded places to help reduce the risk of cross infection, it can be applied to scenarios such as campuses, enterprise, government, etc., and is helpful in preventing and controlling the spread of infectious diseases.

Features

  • Single function, support human body temperature measurement
  • Rapid deployment and easy to use, the temperature can be measured from the wrist or forehead
  • Temperature measurement distance: 1.5″-3.1″ inches, error <0.2˚C
  • Non-contact detection to avoid cross infection
  • Minimizes the margin of error that comes with manual temperature measurement when there is a large
  • Alarm temperature editable: the alarm will be triggered when the it detects the body temperature is over the set value
  • Through the measurement of working environment temperature, flexible adjustment of temperature compensation, improve the accuracy of detection
  • Using PVC synthetic material special process manufacturing, stable structure, environmental protection, non-deformation and long service life

Note: This model does not have the Metal Detector Feature

Dimensions89.4 × 32.7 × 19.7 in








Display Content

When temperature is measured, the display area shows the real-time temperature of the human body and the number of people coming through.

When idle the temperature display will show the temperature of the working environment.

When the running indicator is green, it is ready to operate. When the indicator light turns red, a temperature exceeding the threshold is detected.

Temperature Detection Range0˚C~45˚C 32˚F~133˚F
Temperature Error Variation±0.2˚C ±0.5˚F
Password ProtectionOnly authorized personnel can operate
Power SupplyAC110V/60HZ
Power Consumption<20W
Operating Temperature-10˚C~45˚C 14˚F~113˚F
Operating Humidity<80%
Weight110.23 lbs
Overall Dimension89.4 in x 32.7 in x 19.7 in
Channel Dimension78.7 in x 27.6 in x 19.7 in






Notes

The installation environment should be rainproof, moisture-proof and dry, and the environment temperature balance should be kept as far as possible. High temperature objects should be  kept away from the surrounding environment. Chemical agents such as 84 disinfectant and 75% ethanol disinfectant should be avoided from corroding the outer membrane of the temperature control probe.
