2MBT-5MIR20 5MP TVI Bullet Camera Fixed Lens

  • 4-in-1 bullet camera
  • 1/2.8″Sony335 CMOS 5.0M+NVP2477
  • 18pcs SMD LEDs
  • 20m IR Range
  • Standard match 2.8mm lens

Product Documents

  • 4-in-1 bullet camera
  • 1/2.8″ Sony335 CMOS 5.0M+NVP2477
  • 18pcs SMD LEDs
  • 20m IR Range
  • Standard match 2.8mm lens
  • With 3DNR
  • Default TVI output
Lens

Fixed 2.8mm Lens

Ingress Protection

IP67

Resolution

5 Megapixel (2560 x 1960)

Signal Type

Power System NTSC
Sensor IMX335 1/2.8
DSP NVP2477H
Active Pixel 2560×1944
Sync. Internal
Resolution 5MP
Video Out A/T/C/CVBS
Minimum Illumination 0.01Lux(F1.2)
Gama adjust 0.45
Electric Shutter AUTO FLK 1/25-1/50000
S/N Ratio 48dB(min)(AGC closed)
Noise Reduction 2DNR OFF/LOW/MID/HIGH
3DNR OFF/LOW/MID/HIGH
White Balance ATW/AWC-SET
AGC Level 0-15
D-WDR OFF/Auto
OSD Yes
Language Eng CHN1/2 GER FRA ITA SPA POL RUS POR NED TUR JPN
Day/Night Auto, Color, B/W, Ext
Power Input DC12V±1V
Power Dissipation 85-95MA
Transmission distance 75-5 300M
Operation Temperature Temperature -10℃~+55℃,Humidity less than 85%RH
Weight 0.75kgs
color white+black
