2M Technology 2MT-4008 8 Channel DVR

  •  Hybrid DVR ( TVI,AHD, CVI,CVBS, IP cameras) with adaptive access
  • 8-channel BNC input
  • Support 1-ch HDMI output, 1-ch VGA output at up to 1920*1080
  • Long transmission distance over coax cable
  • Support H.265/H.264 video formats

Product Documents

The 2M Technology 2MT-4008 8 Channel Digital Video Recorder can stream up to 4K resolution cameras. Additionally, the system allows for real time monitoring of video and audio. The DVR runs off of a DV12V power supply and uses a max of 7w. Further, the digital video recorder has an operating temperature range of 0°C- +55°C. The DVR also has face detection and intrusion detection features.

Features:

  •  Hybrid DVR ( TVI,AHD, CVI,CVBS, IP cameras) with adaptive access
  • 8-channel BNC input
  • Support 1-ch HDMI output, 1-ch VGA output at up to 1920*1080
  • Long transmission distance over coax cable
  • Support H.265/H.264 video formats

Signal Type

Number of Channels

PoE Channels

Internal Hard Drives SATA Ports

1 SATA Hard Drives

Series

Essential Series

Resolution

4k – 8 Megapixel (3840 x 2160)

VIDEO/AUDIO INPUT
Analog Video Input8-ch, BNC












IP Video Input

4-ch(only IP up to 12ch),each channel up to 4K
Support AHD input:
8MP@15fps(channel1-channel2)
5MP@20fps
4MP@30fps
3MP@30fps (channel1 –channel2)
1080P@30fps
720P@60fps






Supported Analog Camera Types

Support TVI input: 8MP@15fps(channel1-channel2) 5MP@20fps

4MP@30fps

3MP@20fps (channel1 – channel2) 1080P@30fps

720P@60fps Support CVI input:

8MP@15fps(channel1-channel2) 5MP@20fps 4MP@30fps 1080P@30fps 720P@30fps Support CVBS input

Audio Input1-ch, RCA
Two-way Audio1-ch, RCA
Channel Associated Audio1-ch, RCA
NETWORK
Incoming Bandwidth40Mbps
Outgoing Bandwidth64Mbps
Remote Users128
ProtocolsTCP/IP, P2P, UPnP, NTP, DHCP, PPPoE
VIDEO/AUDIO OUTPUT
CVBS Output1-ch, BNC
VGA Output1920x1080p/60Hz, 1920x1080p/50Hz, 1600×1200/60Hz,

1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz





HDMI Output

1920x1080p/60Hz, 1920x1080p/50Hz,

1600×1200/60Hz,

1280×1024/60Hz,

1280×720/60Hz,

1024×768/60Hz

Audio Output1-ch, RCA
Synchronous Playback8-ch
ENCODING
Recording Resolution8MP Lite/5MP Lite/4MP Lite/3MP/1080P/960P/720P/960H/4CIF/CIF






Recording Frame Rate

Main stream:

8MP Lite@8fps (channel1-channel2) 5MP Lite@12fps 4MP Lite@15fps

3MP@15fps(channel1 – channel2) 2MP@15fps 720P@30fps

Sub stream: D1@30fps(Max)

HARD DISK
SATA1 SATA interfaces
CapacityUp to 10TB for each HDD
EXTERNAL INTERFACE
Network Interface1RJ45 10M/100M self-adaptive Ethernet Interface
USB InterfaceRear panel: 2 x USB2.0
Serial Interface1 x RS485
GENERAL
Power Supply12V DC
Power Consumption≤ 8 W(without HDD)
Working Temperature-10°C ~ + 55°C ( +14°F ~ +131°F )
Working Humidity≤ 90% RH(non-condensing)
Dimensions(W×D× H)260 x 240 x 46 (mm) (10.2″ × 9.4″×1.8″)
Weight (without HDD)≤1.1 Kg ( 4.19lb )
